HL series planetary speed reducer

Product Overview:

Shanghai Guzuo Reducer (Taiwan Nuohong Precision Gear) specializes in the production and sales of precision planetary reducers. The planetary reducer is mainly used with servo motors / stepper motors to increase the output torque and increase the moment of inertia. Can also

be equipped with DC motors, single-phase motors, synchronous motors and various three-phase asynchronous motors.

    The best features of Guzuo HL series method helical planetary reducer are high precision

and large transmission torque. The internal design of the planetary gear structure, special

heat treatment of high-performance alloy steel, flanges and other high-strength aluminum

alloy materials, with beautiful appearance, small size, light weight, high torque, low noise,

high efficiency, long life and so on.

    HL series helical planetary reducer body is fully enclosed, protection grade IP65, filled

with high-performance grease inside, lifetime lubrication and maintenance free for life

。

Model no.：

   HL060 / HL090 / HL120 / HL160

Ratio:

Single level(L1)：3 / 4 / 5 / 7 / 10

Double level(L2): 12 / 15 / 16 / 20 / 25 / 28 / 35 / 40 / 50 / 70 / 100

Triple level（L3): 64 / 80 / 100 / 120 / 125 / 140 / 175 / 200 / 250 / 280 / 350 / 400 / 500 / 700 / 1000

Backlash：

Precision backlash P1：L1≤3arcmin L2≤5arcmin 　L3≤8arcmin

Standard backlash P2：L1≤8arcmin   L2≤10arcmin L3≤12arcmin

Efficiency：

L1：≥ 96%
L2：≥ 94%

L3：≥ 90%

Rated output torque：
   T2N：12 Nm - 885 Nm

Motor power：

57型配HF060: 75W 100W 150W

86型配HF060：90W 150W 200W 300W 450W 750W

86型配HF090：90W 150W 200W 300W 450W 750W

110型配HF090：600W 1000W 1500W 2000W

110型配HF120：600W 1000W 1500W 2000W

130型配HF160：1500W 2000W 3000W 3500W 4000W 4500W 5500W 7500W
